Chapter 3 - Optimize first, then parallelize

When to parallelize, and what to do first...

When your program takes too long, the memory of your machine is too small for your problem or the accuracy you need cannot be met, you're hitting the wall. Parallelization seems necessary, and you feel in need of a supercomputer. However, supercomputers are expensive machines and resources are limited. It should come to no surprise that it is expected that programs are allowed to run on supercomputers only if they make efficient use of their resources. Often, serial programs provide possibilities to improve the performance. These come in two categories: common sense optimizations (often completely overlooked by researchers) which rely on a good understanding of the mathematical formulation of the problem and the algorithm, and code optimizations which rely on understanding processor architecture and compilers. Let's first look at common sense optimizations.

Common sense optimizations

Common sense optimizations come from a good understanding of the mathematical formulation of the problem and seeing opportunities to reduce the amount of work. We give three examples.

1. Magnetization of bulk ferro-magnets

I was asked to speed up a program for computing the magnetization $m(T)$ of bulk ferro-magnets as a function of temperature $T$. This is given by a self-consistent solution of the equations:

$$m = \frac{1}{2 + 4\Phi(m)}$$

$$\Phi(m) = \frac{1}{N} \sum_{\textbf{k}} \frac{1}{e^{\beta\eta(\textbf{k})m} - 1}$$

with $\beta = 1/{k_B T}$. At $T=0$ we have $m(0) = m_0 = 0.5$, and at high $T$, $m(T)$ approaches zero.

The solution is a curve like this:

The program compute this as follows: For any temperature $T$, set $m = m_0$ as an inital guess. Then iterate $m_ {i+1} = 1/(2 + 4\Phi(m_i))$ until $\Delta m = m_{i+1} - m_i$ is small. Here,

$$\Phi(m) = \sum_{n=1}^\infty \frac{a}{\pi} \left(\int_0^{\pi/a} dq e^{-nm\beta\eta_1(q)}\right)^3$$

and the integral is computed using Gauss-Legendre integration on 64 points.

The choice of $m=0.5$ as initial guess is obviously a good one close to $T=0$. However, looking at the graph above, it becomes clear that as T increases the solution moves further and further away from $0.5$. Furthermore, if we compute temperature points at equidistant temperature points, $T_j = \delta j$ for some $\delta$ and $j=0,1,2, ...$, it is also clear that the solution of the previous temperature point, i.e. $m_{j-1}$, is a far better initial initial guess guess than $m_0$. This turns out to be 1.4x faster. Not a tremendous improvement, but as the graph above seems continuous w e can take this idea a step further: using interpolation from solutions a lower temperature points to predict the next solution and use that as an initial guess. Linear interpolation of $m_j$ from $m_{j-1}$ and $m_{j-2}$ gives a speedup of 1.94x and quadratic interpolation from $m_{j-1}$, $m_{j-2}$ and $m_{j-3}$ a factor of 2.4x. That is a substantial speedup achieved without actually modifying the code. This optimization comes entirely from understanding what your algorithm actually does. Investigation of the code itself demonstrated that it made suffered from a lot of dynamic memory management and that it did not vectorize. After fixing these issues, the code ran an additional 13.6x faster. In total the code was sped up by an impressive 32.6x.

2. Transforming the problem domain

At another occasion I had to investigate a code for calculating a complicated sum of integrals in real space. After fixing some bugs and some optimization to improve the efficiency, it was still rather slow because the formula converged slowly As the code was running almost at peak performance, so there was little room for improvement. However, at some point we tried to apply the Fourier transform to get an expression in frequency space. This expression turned out to converge much faster and consequently fewer terms had to be computed, yielding a speedup of almost 2 orders of magnitude and was much more accurate. This is another example of common sense optimization originating in a good mathematical background. The natural formulation of a problem is not necessarily the best to use for computation.

3. Transforming data to reduce their memory footprint

I recently reviewed a Python code by the Vlaamse Milieumaatschappij for modelling the migration of invertebrate aquatic species in response to improving (or deteriorating) water quality. The program read a lot of data from .csv files. For a project it was necessary to run a parameter optimization. That is a procedure where model parameters are varied until the outcome is satisfactory. If the number of model parameters is large the number of program runs required can easily reach in the 100 000s. The program was parallelized on a single node. However, the program was using that many data that 18 cores of the 128 cores available on a node already consumed all the available memory. By replacing the data types of the columns of the datasets with datatypes with a smaller footprint, such as replacing categorical data with integer IDs, replacing 32-bit integers with 16-bit or even 8-bit integers, float64 real numbers with float32 or float16 numbers reduced the amount of data used by a factor 8. All of a sudden much more cores could be engaged in the computation and the simulation sped up considerably.

Some of these "common sense optimizations" may seem obvious. Yet, of all the codes I reviewed during my career, few of them were immune to common sense optimization. Perhaps, developing (scientific) software takes a special mindset:

!!! tip The scientific software developer mindset: Constantly ask yourself 'How can I improve this? How can I make it faster, leaner, more readable, more flexible, more reusable, ... ?'

Common sense optimizations are optimizations that in general don't require complex code analysis, require very little code changes and thus little effort to implement them. Yet they can make a significant contribution.

Code optimizations

Code optimizations are optimizations aiming at making your solution method run as efficient as possible on the machine(s) that you have at your disposal. This is sometimes referred as code modernization, because code that was optimized for the CPUs of two years a go may well need some revision for the latest CPU technology. These optimizations must, necessarily, take in account the specific processor architecture of your machine(s). Important topics are:

• Avoid pipeline stalls (due to unpredictable branches, e.g.) - Ensure SIMD vectorization. On modern processors vector registers can contain 4 double precision floating point numbers or 8 single precision numbers and vector instructions operate on these in the same number of cycles as scalar instructions. Failing to vectorize can reduce the speed of your program by a factor up to 8x! - Smart data access patterns are indispensable for programs with a memory footprint that exceeds the size of the cache. Transferring data from main memory (DRAM) to the processor's registers is slow: typical latencies are in the order of 100 cycles (which potentially wastes ~800 single precision vectorized operations). Vector instructions are of no help if the processing unit must wait for the data.

This is clearly much more technical and complicated (in the sense that it requires knowledge from outside the scientific domain of the problem you are trying to solve). Especially fixing memory access patterns can be difficult and a lot of work, as you may have to change the data structures used by your program, which usually also means rewriting a lot of code accessing the data. Such code optimizations can contribute significantly to the performance of a program, typically around 5-10x, but possibly more. As supercomputers are expensive research infrastructure in high demand, we cannot afford to waste resources. That being said, the lifetime of your program is also of importance. If you are developing a code that will be run a few times during your Master project or PhD, using only a hundred of node days, and to be forgotten afterwards, it is perhaps not worth to spend 3 months optimising it.

Often, however, there is a way around these technicalities. If the scientific problem you are trying to solve, can be expressed in the formalism of common mathematical domains, e.g. linear algebra, Fourier analysis, ..., there is a good chance that there are good software libraries, designed with HPC in mind, that solved these problems for you. In most cases there are even bindings available for your favorite programming language (C/C++, Fortran, Python, ...). All you have to do is translate the mathematical formulation of your problem into library calls.

Tip

Use HPC libraries as much as possible. There is little chance that you will outperform them. Quite to the contrary: your own code will probably do significantly worse. By using HPC libraries you gain three times: - you gain performance, - you gain development time as you will need a lot less code to solve your problem, less debugging, simpler maintenance, ... - your learn how to use the library which will get you at speed readily when you take on your next scientific problem.

Tip

Don't reinvent the wheel. The wheel was invented ~8000 years ago. Many very clever people have put effort in it and is pretty perfect by now. Reinventing it will unlikely result in an improvement. By extension: if you need some code, spend some time google-ing around to learn what is already available and how other researchers attack the problem. It can save you weeks of programming and debugging. Adapting someone else's code to your needs will learn you more than coding it from scratch. You'll discover other approaches to coding problems than yours, other language constructs, idioms, dependencies to build on, learn to read someone else's code, learn to integrate pieces.

When is code optimized well enough?

Tip

Premature optimization is the root of all evil Donald Knuth.

This quote by a famous computer scientist in 1974 is often used to argue that you should only optimize if there is a real need. If code is too slow, measurements (profiling) should tell in which part of the code most time is spent. That part needs optimization. Iterate this a few times. Blind optimization leads to useless and developer time-wasting micro-optimizations rendering the code hard to read and maintain. On the other hand, if we are writing code for a supercomputer, it better be super-efficient. But even then, depending on the lifetime of the program we are writing, there is a point at which the efforts spent optimising are outweighed by having to wait for the program going in production.

How can one judge whether a code needs further optimization or not? Obviously, there are no tricks for exposing opportunities for common sense optimizations, nor for knowing whether better algorithms exist. That is domain knowledge, it comes with experience, and requires a lot of background. But for a given code and given input, can we know whether improvements are possible? In Chapter 1 we mentioned the existence of machine limits, the peak performance, $P_p$, the maximum number of floating point operations that can be executed per second, and the bandwidth, $B$, the maximum number of bytes that can be moved between main memory and the CPU's registers per second. It is instructive to study how these machine limits govern the maximum performance $P_{max}$ as a function of the computational intensity $I_c$. If the CPU must not wait for data, $P_{max} = P_p$. In the situation where the bandwidth is limiting the computation $P_{max} = BI_c$. This leads to the formula:

$$P_{max} = min(P_p,BI_c)$$

This is called the roof-line model, since its graph looks like a roof-line.

We can measure the actual performance and computational intensity of the program and plot it on the graph. The point must necessarily be under the roof-line. For a micro-benchmark, such as a loop with a simple body, we can compute $I_c$ by hand, count the Flops and time the benchmark to obtain the computational intensity. For an entire program a performance analysis tool can construct the graph and measure where the program is in the graph. Let's discuss 4 different cases, corresponding to the four numbered spots in the graph above.

1. Point 1 lies in the bandwidth limited region, but well below the roof-line. Something prevents the program to go at the maximum performance. There can be many causes: bad memory access causing cache misses, the code may fail to vectorize, pipeline stalls, ... for a micro-benchmark you can perhaps spot the cause without help. For a larger program a performance analyzer will highlight the problems.
2. Point 2 lies in the peak performance limited region, also well below the roof-line. Hence, cache misses are unlikely the cause.
3. Point 3 lies close to the roof-line and the boundary between the bandwidth limited region and the peak performance limited region. This the sweet spot. Both peak performance and bandwith are fully used.
4. Point 4 lies close to the roof-line in the peak performance limited region. This is an energy-efficient computation at peak performance. It moves little data (high $I_c$). Moving data is by far the most energy consuming part in a computation.

Common approaches towards parallelization

Before we discuss common parallelization approaches, we need to explain some concepts:

• process (wikipedia): "In computing, a process is the instance of a computer program that is being executed by one or more threads." A process has its own address space, the region of main memory that can be addressed by the process. Normally, a process cannot go outside its address space, nor can any other process go inside the process's own address space. An exception is when both processes agree to communicate, which is the basis of distributed memory parallelism (see below). In general, a process is restricted to a single node, and the maximum number of parallel threads is equal to the number of cores on that node.
• thread (wikipedia): "In computer science, a thread of execution is the smallest sequence of programmed instructions that can be managed ...". The instructions in a thread are thus by definition sequential. In the context of parallel computing, parallel threads are managed by the parent process to run different tasks in parallel. Obviously, parallel threads need to run on distinct cores to be truly concurrent. As threads belong to a process, they can in principle have access to the entire address space of the process. Sometimes a distinction is made between hardware threads and software threads. A software thread is a set of sequential instructions for a computational task that is scheduled by the program to execute. When its execution starts, it is assigned to a core. software threads can be interrupted, in order to let the core do other, more urgent work, e.g., and restarted. There can be many more software threads in a program than it has cores available, but, obviously, they cannot all run in parallel. Software threads are very useful in personal computers with many interactive applications opened simultaneously, where are many non-urgent tasks. For HPC applications they are a bit heavy-weight. A hardware thread is a lightweight software thread that is exclusively tied to a core. When given work, it can start immediately and runs to completion without interruption. That is certainly useful in HPC where not loosing compute cycles is more important than flexibility.

Now that we understand the concepts of processes and threads, we can explain three different types of parallelization:

Shared memory parallelization

In shared memory parallelization there is one process managing a number of threads to do work in parallel. As all the threads belong to the same process, they have access to the entire memory address space, that is, they share memory. To avoid problems, as well as for performance reasons, the variables inside a thread are private by default, i.e. they can only be accessed by the thread itself, and must be declared shared if other threads should have access too. Cooperating threads must exchange information by reading and writing to shared variables. The fact that all the threads belong to the same process, implies that shared memory programs are limited to a single node, because a process cannot span several nodes. However, there exist shared memory machines larger than a typical supercomputer node, e.g. SuperDome at KU leuven. Such systems allow to run a shared memory program with much more threads and much more memory. This approach can be useful when distributed memory parallelization is not feasible for some reason.

The most common framework for shared memory parallelization is OpenMP. OpenMP parallelization of a sequential program is relatively simple, requiring little changes to the source code in the form of directives. A good starting point for OpenMP parallelization is this video. An important limitation of OpenMP is that it is only available in C/C++/Fortran, and not Python. Fortunately, Python has other options, e.g. multiprocessing, concurrent.futures and dask. In addition, it is possible to build your own Python modules from C++ or Fortran code, in which OpenMP is used to parallelize some tasks. The popular numpy is a good example.

PGAS

PGAS, or Partitioned Global Address Space, is a parallel programming paradigm that provide communication operations involving a global memory address space on top of an otherwise distributed memory system. it therefore acts as a shared memory parallelization.

Distributed memory parallelization

Distributed memory parallelization is the opposite of shared memory parallelization. There are many process, each with only a single-thread. Every process has its own memory address space. These address spaces are not shared, they are distributed. Therefor, explicit communication is necessary to exchange information. For processes on the same machine (=node) this communication is intra-node, but for processes on distinct machines messages are sent over the interconnect.

Distributed memory programs are considerably more complex to write, as the communication must be explicitly handled by the programmer, but may use as many processes as you want. Transformation of a sequential program into a distributed memory program is often a big programming effort. The most common framework is MPI. MPI is available in C/C++/Fortran and also in Python by the mpi4py module.

Hybrid memory parallelization

Hybrid memory parallelization combines both approaches. It has an unlimited number of processes, and a number of threads per process, which run in parallel in a shared memory approach (OpenMP). The process communicate with each other using MPI. Typically, the computation is organized as one proces per NUMA domain and one thread per core in dat NUMA domain.
This approach uses shared memory parallelization where it is useful (on a NUMA domain), but removes the limitation to a single machine. It has fewer processes, and thus less overhead in terms of memory footprint, and communication overhead. It is also a bit more complex that pure distributed memory parallelization, and much more complex than shared memory parallelization.

Hybrid memory parallelization is usually implemented with OpenMP at the shared memory level and MPI at the distributed level.
